Fitness Equipment Single Acting Hydraulic Oil Cylinder Customization
Lefang hydraulic manufacturing facilities operate under the ISO 9001:2008 quality certificate. We pride ourselves in only using high-quality materials and innovative technologies in order to produce the finest heavy-duty hydraulic cylinders. Our manufacturing and design techniques provide product reliability in extreme stress and conditions. Therefore our products are perfectly suited for severe weather conditions from tundra to tropics. It is our purpose to satisfy any rigorous hydraulic demands.
Product Description:
1.Single-acting
2.Superior Quality Chrome Plated & Polished Rod
3.Honed & Finished Steel Tube
4.Top Quality Seals
5.Color could be as per requirements.
Our Services
12 months or more, and we supply top quality and best service always.
Packaging & Shipping
1. Packing: Steel Pallet, Plywood Case, or As per requirements.
2. Shipping: By sea, By air, or By express company.
| Material : |
| Piston: 45# steel |
| Tube: 20# steel |
| Piston rod: chrome plated 45# steel |
| Cylinder cap: 20# steel |
| Cylinder base: 20# steel |
| Seal ring: famous Chinese brand or international brand |
Max.Cylinder Bore 300mm
Max.Piston Rod Dia. 280mm
Max.Retract Length 3500mm
Max .Stroke Single stage cylinder 6500mm
Multi-stage cylinder 12000mm
Max.Working Pressure 35Mpa
Min.Working Pressure 10Mpa
Working Pressure of Heavy-duty Cylinder 40Mpa
