HSG Standard Welded Hydraulic Cylinders hydraulic ram
Product Details
LEFANG experienced professional engineering staff can design hydraulic cylinders for any application with a focus on safety, reliability, and performance. LEFANG hydraulic cylinders perform critical functions in many industries, and our design team listens and learns all about each application, so that our hydraulic cylinders will function perfectly and reliably.
Material:
| Material : |
| Piston: 45# steel |
| Tube: 20# steel |
| Piston rod: chrome plated 45# steel |
| Cylinder cap: 20# steel |
| Cylinder base: 20# steel |
| Seal ring: famous Chinese brand or international brand |
| PARAMETER | |
| Max.Cylinder Bore | 300mm |
| Max.Piston Rod Dia. | 280mm |
| Max.Retract Length | 3500mm |
| Max .Stroke | Single stage cylinder 6500mm |
| Multi-stage cylinder 12000mm | |
| Max.Working Pressure | 35Mpa |
| Min.Working Pressure | 10Mpa |
| Working Pressure of Heavy-duty Cylinder | 40Mpa |
Structure: Piston Cylinder
Power: Hydraulic
Place of Origin: Shandong, China (Mainland)
Brand Name: LF
Colour: yellow,orange,red,blue,black,green etc.
Min.Order Quantity: 10 Piece/Pieces
Supply Ability: 1000 Piece/Pieces per Month
Port: Qingdao, China
HSG Standard Welded Hydraulic Cylinders
